Finalizing the Installation 29
© Travis Industries 4140808 100-01298
3. Remove the front burner as shown below.
4. Install the firebacks. See the firebacks installation instructions for details.
5. Replace the front burner as shown.
6. Replace the rear burner as shown.
7. Re-attach the burner attachment screws (see step 1 above).
The two tabs on the
rear burner rest on top
of the front burner.
To Next Page
