Trek 2022 SESSION - Active Braking Pivot

2022 Session Service Manual
9
Active Braking Pivot
1
3
4
5
4
2
Item Description Quantity in
Assembly
Part Number Torque (Nm)
1 Thru axle 1 W598581 10
2 Dropout axle 1 W5251141 15
3 Retaining ring 1 W5251279 —
4 Bearing 2 W583424 —
5 Non-drivesidedropout 1 W583419 —
Tools
• Bearing press
• 8mm hex tool
• Torquewrench(left-handthread)with8mmhexbit
• Cassette lockring
• Grease
1. Pressinthedrivesidebearing(4).
2. Pressinthenon-drivesidebearing(4).
3. Placetheretainingring(3)overthenon-driveside
bearing.
4. Applygreasetothenon-drivesidedropout(5).
5. Installthenon-drivesidedropout(5).
6. Applygreasetothedropoutaxle(2).
7. Insertthedropoutaxle(2)intotheoutsideofthe
non-drive side.
8. Applygreasetothethreadsofthethruaxle(1),
and a lighter amount of grease to the shaft of
thethruaxle(1).
9. Insert the thru axle into the dropout.
10. Torquethethruaxleto10Nm.
