2022 Session Service Manual
13
Cabling
The Session ships with cables routed internally, but includes options for routing cables externally for quick component
changes or repairs.
Internal cable routing




1
2
6
3
Optional external cable routing




1
2
5
3
2
4
6
3
Item Description
Quantity in
Assembly Part Number Torque (Nm)
1 Rear brake cable 1 — —
2 Socket head cap screw 3 W5256244 3
3 Dual cable guide 3 W311726 —
4 Flat head bolt 1 W532763 3
5 Guide assembly 1 W502054 —
6 Derailleur cable 1 — —

Zip tie location 2 — —
