TREND HINGE/JIG - SPARE PARTS - Spare Parts List

-15-
HINGE JIG & H/JIG/A
No. Qty Desc. Ref.
1 1 Aluminium Template (HINGE/JIG) WP-HJ/01
1A 1 Aluminium Template Upper (Short) (H/JIG/A) WP-HJ/01A
1B 1 Aluminium Template Lower (Long) (H/JIG/A) WP-HJ/01B
2 5 Aperture Block WP-HJ/02
3 2 Upper Edge Stop WP-HJ/03
4 2 Lower Edge Stop WP-HJ/04
5 1 End Block WP-HJ/05
6 1 Swivel End Plate WP-HJ/06
7 1 End Bung WP-HJ/07
8 2 Nylon Spacer WP-HJ/08
9 2 Bradawl WP-HJ/09
10 1 Feeler Gauge 4mm WP-HJ/10
11 1 Hinge Jig Label WP-HJ/11
12 5 Jointing Block - H/JIG/A WP-HJ/12
13 5 Machine Screw Csk M6 x 16mm Skt WP-SCW/51
14 2 Machine Screw Csk M6 x 40/18mm Skt WP-SCW/52
15 1 Machine Screw Small Csk M6 x 12mm Skt WP-SCW/56
16 2 Split Pin 3mm x 25mm WP-PIN/01
17 1 Hex Key ‘T’ Handle 4mm WP-AKT/01
18 1 Guide Bush 16mm Dia. x 10mm Spigot GB160
19 1 Storage Tube (HINGE/JIG) CASE/HJ
20 1 Carry Case (H/JIG/A) CASE/HJ/A
21 1 Manual MANU/HJ
HINGE/JIG & H/JIG/A - SPARE PARTS LIST v6.0 02/2011
Please use only Trend original spare parts.
MANU-HJ v7.0 3/5/11 11:37 Page 15
