CLI Configuration
Node
Command
Description
enable
show storm-control
This command displays the current
storm control configurations.
configure
storm-control rate RATE_LIMIT
type (bcast | mcast | DLF |
bcast+mcast | bcast+DLF |
mcast+DLF | bcast+mcast+DLF)
ports PORTLISTS
This command enables the
bandwidth limit for broadcast or
multicast or DLF packets and set
the limitation.
configure
no storm-control type (bcast |
mcast | DLF | bcast+mcast |
bcast+DLF | mcast+DLF |
bcast+mcast+DLF) ports
PORTLISTS
This command disables the
bandwidth limit for broadcast or
multicast or DLF packets.
Example:
[DEVICE_NAME]#configure terminal
[DEVICE_NAME](config)#storm-control rate 1 type broadcast ports 1-6
[DEVICE_NAME](config)#storm-control rate 1 type multicast ports 1-6
[DEVICE_NAME](config)#storm-control rate 1 type DLF ports 1-6
Web Configuration
Advanced Settings > Bandwidth Control > Rate Limitation > Storm Control
Parameter
Description
Port
Select the port number for which you want to configure storm control
settings.
Rate
Select the number of packets (of the type specified in the Type field) per
second the Switch can receive per second.
Type
Select Broadcast - to specify a limit for the amount of broadcast packets
received per second.
Multicast - to specify a limit for the amount of multicast packets
received per second.
DLF - to specify a limit for the amount of DLF packets received per
second.
Apply
Click Apply to take effect the settings.
Refresh
Click Refresh to begin configuring this screen afresh.
