TRENDnet TI-PG541i - Page 75

© Copyright 2019 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Industrial Managed Switch Series
72
0x0333
(port 10)
Word 4 Hi byte = ‘4’
Word 4 Lo byte = ‘5’
Word 5 Hi byte = ‘.’
Word 5 Lo byte = ‘\0’
0x0400 to
0x0413
(port 1 to
10)
2 words
HEX
Port 1 to 10 Tx Packets
Ex: port 1 Tx Packet Amount =
0x87654321
Word 0 =8765
Word 1 = 4321
0x0440 to
0x0453
(port 1 to
10)
2 words
HEX
Port 1 to 10 Rx Packets
Ex: port 1 Rx Packet Amount =
0x123456
Word 0 = 0012
Word 1 = 3456
0x0480 to
0x0493
(port 1 to
10)
2 words
HEX
Port 1 to 10 Tx Error Packets
Ex: port 1 Tx Error Packet Amount =
0x87654321
Word 0 =8765
Word 1 = 4321
0x04C0 to
0x04D3
(port 1 to
10)
2 words
HEX
Port 1 to 10 Rx Error Packets
Ex: port 1 Rx Error Packet Amount =
0x123456
Word 0 = 0012
Word 1 = 3456
STP Information
0x0500
1 word
HEX
STP Status:
0x0000 : STP is disabled.
0x0001 : STP
0x0002 : RSTP
0x0003 : MSTP
Xpress Ring Information
0x0501
1 word
HEX
Xpress Ring Status on the Switch:
0x0000 : Disabled.
0x0001 : Enabled
0x0510
1 word
HEX
Status of Xpress-ring1 of the Switch
0x0000 : Disabled
0x0001 : Enabled
0x0511
1 word
HEX
Status of Xpress-ring2 of the Switch
0x0000 : Disabled
0x0001 : Enabled
0x0512
3 word
HEX
Destination MAC of the Xpress-ring1
Word 0 Lo byte = MAC0
Word 0 Hi byte = MAC1
Word 1 Lo byte = MAC2
Word 1 Hi byte = MAC3
Word 2 Lo byte = MAC4
Word 2 Hi byte = MAC5
0x0515
3 word
HEX
Destination MAC of the Xpress-ring2
Word 0 Lo byte = MAC0
Word 0 Hi byte = MAC1
Word 1 Lo byte = MAC2
Word 1 Hi byte = MAC3
Word 2 Lo byte = MAC4
Word 2 Hi byte = MAC5
0x0518
1 word
HEX
Primary Port of the Xpress-ring1
Word 0 Hi byte = Port ID.
0x0519
1 word
HEX
Secondary Port of the Xpress-ring1
Word 0 Hi byte = Port ID.
0x051a
1 word
HEX
Primary Port of the Xpress-ring2
