UVM-1000

LIT-12013155

Figure 13. Factory Cong Settings Tab

Typically the input value will be between 0 and 4095. The

second eld is the input A/D as a percentage of 4095. The third

eld is (4095 – A/D input) as a percentage of 4095. The values

can be used as a rough guide as to where the input signal is

relative to the full range. This input is used as the raw input prior

to scaling of an analog pressure sensor.

Each of the input A/D count sections have a voltage eld that

indicates the approximate voltage at the input based on the A/D

and the calibration factors on the Factory Cal page.

The FeedBack Output eld is used to check or control (when

overridden) the Vo signal that is used as the 0 -10 V feedback

signal to the third party controller. Clicking the Get Feedback

Output Raw Value button will return the raw value (0 – 4095)

being sent to the D/A for the Vo channel. If the Vo channel is

overridden by checking the Override AO 1 (Vo) on the User

Settings Tab, the output on Vo can be set by the user (for debug).

Enter a value between 0 and 1000 (100.0%) in the feedback text

box and click Set Feedback Output Override Value button so that

the Vo output goes to a value between 0 and 10 V.

The Actuator Output eld is used to check or control (when

overridden) the Io signal that is used as the 4 -20mA actuator

control signal.

Clicking the Get Actuator Output Raw Value button will return the

raw value (0 – 4095) being sent to the D/A for the Io channel. If

the Io channel is overridden by checking the Override AO 2 (Act)

on the User Settings Tab, the output on Io can be set by the user

(for debug).

Enter a value between 0 and 1000 (100.0%) in the Act text box

and click Set Actuator Output Override Value button so that the

Io output goes to a value between 4 and 20 mA.

The two output sections also have a voltage eld that show

the approximate voltage out based on the control value and

calibration factors on the Factory Cal section.

Factory Cong Settings Tab

See Figure 13.

Dynamic Values Tab and Factory Cong Settings Tab

TRIATEK UVM-1000 User Manual
