JACE-6 Mounting and Wiring Instructions
Published: April 19, 2007 Part Number 10821
Wiring Details
Power Wiring
10
Power Wiring
The JACE-6 must be powered by an approved 15 Vdc power source. This can be either
1
an external wall mount
AC adapter (WPM-XXX), a DIN-mount 24Vac/dc-powered module (NPB-PWR), or a DIN-mount line
line-powered (90–263 Vac) module (NPB-PWR-UN).
The JACE-6 controller does not include an on/off switch. To apply power, you either:
• if WPM-XXX, plug in the power connector to the JACE-6.
• if NPB-PWR, plug in its 2-position power connector.
• if NPB-PWR-UN, energize the AC circuit (90–263 Vac) wired to that module.
Caution Do not connect both the WPM-XXX and NPB-PWR / NPB-PWR-UN supplies at the same time, or
equipment damage may result.
If desired, you can use the wall mount WPM-XXX in your office (to initially commission the JACE-6), and then
install the JACE-6 at the job using either an NPB-PWR or NPB-PWR-UN module. The following sections
provide more details:
• WPM-XXX (Wall Power Modules)
• NPB-PWR (24Vac/dc-powered in-line module)
• NPB-PWR-UN (Universal 90V–263Vac-powered in-line module)
WPM-XXX
All models of wall power modules (US, EUR, UK, JA) are self-contained, isolated, switching power supplies
designed to plug into a standard building power receptacle of appropriate voltage. To supply power to the
JACE-6, you then simply plug the barrel connector plug from the WPM-XXX into the barrel power connector
on the JACE-6 base board (see Figure 5 on page 13).
Caution Do not plug the barrel connector plug from the WPM-XXX into the JACE-6 until all other mounting
and wiring is completed. See “Power Up and Initial Checkout,” page 15.
NPB-PWR
Using the NPB-PWR module lets you power the JACE-6 (and if installed, IO-16 modules) from a dedicated
Class 2, 24Vac transformer, or from a 24Vdc power supply. If installing IO-16 modules, the NPB-PWR installs
as the last (end) module in the chain. See Figure 1 on page 5.
1. In some markets, a fourth power option is available: an IO-34 accessory module, which is a combination of the
NPB-PWR module and two IO-16 modules (plus two extra relays). Please refer to its mounting and wiring instructions
document for more details. For general information on accessory modules, see “About Accessory Modules,” page 8.
