TRIMOS V9 User Manual

V7 / V9
750 50 0042 03 21
6.3 Min, Max and Delta Modes
Max = Measurement of maximum value ( )
Min = Measurement of minimum value ( )
Delta = Difference between Max and Min ( )
Measurements in
Min
,
Max
and
Delta
modes have
always to be taken with the probe being in contact with
the surface.
It allows to determine the following values:
Min
: Minimum value of the measured surface
Max
: Maximum value of the measured surface
Delta
: Difference between the maximum and minimum
value
To select the
Min
,
Max
or
Delta
measuring mode, press
the key shown alongside. By pressing the same key
several times, the required mode will be displayed.
Note:
In manual mode, the difference between the Min and the
Max should not exceed ± 1 mm. When motorisation is
activated, a closed-loop control is used to monitor the
surface over the entire measuring range of the instrument.
Max
Delta
Min
