TRIMOS V9 User Manual

User's Manual
750 50 0042 03 64
7. Box checked: Automatic transfer of data after each
probe.
Note:
When
AUTO
is checked, only the value (s) selected for
the first press of the
Data transfer key
is active. This
option is not available for transfer to a USB printer.
12.3 Data Transfer via USB B
Connection to a PC
A USB A-B cable is required for the connection to a PC,
as well as the TrimosDataTransfer communication
software.
Cable
USB A-B connection cable: TA-EL-013 (ref. 332 02 0001)
Software
The TrimosDataTransfer software is freely available on
www.trimos.com, in the corresponding product section.
Data transfer procedure
1. Start TrimosDataTransfer
2. Connect the instrument to the PC with TA-EL-013
cable and wait for the connection to be established
3. Click on the application to which the data has to be
transferred.
4. Press
Data transfer key.
The value is displayed at the
place having the focus. The data can also be sent
automatically after each probing (§ 12.2).
Format
Numerical value (as on display) in ASCII characters.
In diameter/centreline mode, if 2 values are sent
simultaneously, they are separated by a LF (Line Feed).
