13-5
CLASS C MOTORHOME
CAUTION
Do not allow the holding tanks to
overfill as this could cause waste to
back up through the toilet or the
bathtub/shower drain.
IMPORTANT
The master switch for the water pump is
also located on the monitor panel.
13.4 MONITOR PANEL
The monitor panel covers four systems in
your motorhome:
1. Battery:
Indicates the level of charge in the
auxiliary battery.
2. Propane:
Indicates the level of propane in the
propane tank.
3. Fresh Water:
Indicates the amount of fresh water in
the fresh water tank.
4. Holding Tanks:
Indicates the amount of waste in the
13.5 WATER HEATER BY-
PASS VALVE
See Section 17.2 for cold weather preparation
instructions.
Fig. 13-6 MONITOR PANEL
grey water and black water holding tanks.
To check the level for any of the systems, press
the button for the system you are checking and
read the level.
Fig. 13-7 BYPASS VALVE
