12-11
CLASS C MOTORHOME
12.2.6 HOLDING TANK LEVEL
INDICATORS
The holding tank levels may be checked on
the monitor panel. Press the correspond-
ing switch to check the level in each tank.
12.3 PLUMBING SYSTEM
OPERATION
12.3.1 WATER HEATER
The motorhome is equipped with a 6 gallon water
heater. The water may be heated in one of three ways:
1. With an LP gas burner.
2. With a 120-volt heating element (optional)
3. With an automotive engine heater
while driving. (optional)
1. LP Gas Operation:
To ignite the heater, set the
waterheater switch located on the
range hood.
Regency/Senator Senator XL
Fresh 36 (136) 36 (136)
Grey 32 (243) 32 (243)
Black 32 (243) 32 (243)
Tank Capacities
12.2.7 TANK CAPACITIES
Fig. 12-11 TANK LEVEL INDICATORS
Fig. 12-12 WATER HEATER SWITCH
IMPORTANT
Be sure there is water in the
hot water tank to prevent
burning out the heating
element when the power is
turned on.
