13-8
CLASS C MOTORHOME
13.8 CABLE TV HOOK-
UPS
See the separate instruction manual in your infor-
mation packet labelled converter.
The converter is located under the dinette seat.
13.9 DC-AC ELECTRICAL
VOLTAGE CONVERTER
Exterior
Bedroom
Bedroom
Control
Fig. 13-10 CONVERTER
13.10 SLEEPING FACILITIES
Do not use sleeping facilities while motorhome is
in motion.
WARNING
1. Bedroom:
Standard sleeping facilities with a bed are
located at the rear of the coach.
2. Rear Auxiliary Heater Control (XL Only):
A rear heater is located under the bed. This
heater will only generate heat when the chassis
engine is running. The control for this heater is
located as shown and is push/pull activated.
Fig. 13-11 REAR HEATER
