Triple E EMPRESS SERIES - 16 Storing Your RV

13-7
EMPRESS
13.12
VIDEO CASSETTE RECORDER
or DVD/VCR COMBO
(Optional)
Refer to manufacturer's manual in the Owner's
Information Package for operating instructions and
maintenance information. The VCR is powered by
120-volt through the inverter.
13.13
VIDEO CONTROL CENTER
Refer to manufacturer's manual for operating
instructions and maintenance information.
13.14 PHONE / CABLE TV &
SATELLITE HOOK-UPS
To hook-up the cables raise the covers and connect
VCR & VIDEO CONTROL CENTER
PHONE/CABLE/SATELLITE
a
b
c
VCR & VIDEO CONTROL CENTER
13.15 SLEEPING FACILITIES
1.
Bedroom:
Standard sleeping facilities with a bed are
located at the rear of the coach.
2.
Rear Heater Control:
A rear heater temperature and 2-speed fan
control switch is located on the dashboard.
Depress the bottom portion of the switch to turn
the fan on and the top portion of the switch to
turn it off. When the fan switch is switched 'on'
the rear auxilary heater water valve will open and
when the switch is switched 'off' the water valve
3.
Sofa/Bed Conversion:
The front sofa converts into a bed. To convert to
bed:
a. Slide the latch handle sideways and lift the
sofa seat up from the base.
b. Pull forward until the back drops down to a
bed position.
To convert back to a sofa:
a. Lift and push the sofa back against the
wall.
The sofa has a convenient drawer located below.
4.
Hide-a-Bed:
a. Move the cocktail chair as far back as
possible.
b. Remove the hide-a-bed cushions.
c. Release the safety latch and lift out the bed
by pulling up on the centre of the front bar
and fold it open.
d. Reverse the procedure to convert back to a
Do not use sleeping facilities while motorhome is
in motion.
WARNING
REAR HEATER CONTROL SWITCH
