Tripp Lite NetCommander B070-016-19-IP2 User Manual

34
2. Web Configuration Interface
2.4.10 Serial Ports
The Serial Ports page is where you configure the settings of the serial device(s) that you have connected to the KVM. (See section 5. Serial
Port Pinout for pinout information).
To configure the serial port settings:
1. From the Configuration section, select the Serial Ports tab. The Serial Ports page appears.
2. For each serial device connected, enter an appropriate Device Name, and then set the Baud Rate, Parity, Data Bits and Stop Bits
settings accordingly.
3. Click the Save button at the top of the screen to save your changes.
2.4.11 Security
The Security section allows you to configure the security features of the KVM, such as Account Blocking, Password Policy, Idle Timeout, and
Serial Terminal Policy.
To configure the security settings:
1. From the Configuration section, select the Security tab. The Security page appears.

Tripp Lite NetCommander B070-016-19-IP2 Specifications

General

Display diagonal	19 \
Display resolution	1280 x 1024 pixels
On Screen Display (OSD)	Yes
Product color	Black
Country of origin	Taiwan
Security algorithms	128-bit AES, 802.1x RADIUS, HTTPS
Height (in Rack Units)	1
KVM switch ports quantity	16
Operating temperature (T-T)	-4 - 140 °F
Sustainability certificates	RoHS
Certification	UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1
Input current	1.2/0.7 A
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Interface	PS/2; USB; VGA
Storage temperature (T-T)	-20 - 60 °C
Package depth	891.5 mm
Package width	591.8 mm
Package height	149.9 mm
Package weight	19780 g
Master (outer) case width	595.1 mm
Master (outer) case height	150.1 mm
Master (outer) case length	833.9 mm
Master (outer) case weight	17960 g
Quantity per master (outer) case	1 pc(s)

Weight and Dimensions

Depth	692.4 mm
Width	477.3 mm
Height	43.4 mm
Weight	12910 g
