63
7. Technical Specifications
Specification Description
Operating systems Target Server – Windows
Client computer – Windows with Internet Explorer, Firefox, or Chrome browsers
Max Resolution (Local Console Monitor)
1366 x 768
Distance from Switch to SIUs
Up to 100 ft. (30 m)
Security
SSL, high grade 128-bit AES encryption
Connections Ethernet – (x2) RJ45 – 10/100 Mbps
Serial – (x2) RJ45
Server – (x16) RJ45 – 116IP / (x8) RJ45-108IP
Power input
100-240 VAC, 50/60 Hz
Operating temperature
32° to 104°F / 0° to 40°C
Storage temperature
-40° to 158°F / -40° to 70°C
Humidity
80% non-condensing relative humidity
Specification B078-101-PS2 SIU B078-101-USB-1 B078-101-USB2
Connections VGA – HD15
KM – (x2) MiniDin6
System – RJ45
VGA – HD15
KM – USB
System – RJ45
VGA – HD15
KM – USB
FVM – USB
System – RJ45
Power
From Keyboard port From USB port From USB port
8. Video Resolution and Refresh Rates
Hz 56 60 65 66 70 72 73 75 76 85 86
640x480
x x x x x x
720x400
x x
800x600
x x x x x x
1024x768
x x x x x x x
1152x864
x
1152x900
x x
1280x720
x
1280x768
x x
1280x960
x x
1280x1024
x x x x x
1600x1200
x
1920x1080
x
1920x1200
x
Note: The local console monitor on the B070-16-19-IP2 supports video resolutions up to 1366 x 768.
