8
DIMENSIONS & ENTRY POINTS
2
check list
SECTION SECTION
Fig.2
Fig.1
200mm
94mm
300mm
ENTRY POINTS
DIMENSIONS
WATER
Left: Top, Bottom & Back.
Right: Bottom & Back.
CABLE
Left: Top, Bottom & back.
Right: None.
= Back
= Back
= Others
= Others
PLEASE NOTE: Deviation from the
approved entry points will invalidate
product specifications and warranty.
