Triumph Daytona Moto2 765 2020 User Manual

Maintenance
108
To lubricate the drive chain:
• Use the special drive chain lubricant
as recommended in the
Specifications section.
• Apply lubricant to the sides of the
rollers then allow the motorcycle to
stand unused for at least eight
hours (overnight is ideal). This will
allow the lubricant to penetrate to
the drive chain O-rings etc.
• Before riding, wipe off any excess
lubricant.
• If the drive chain is especially dirty,
clean first and then apply lubricant
as mentioned above.
Caution
Do not use a pressure washer to clean
the drive chain as this may cause
damage to the drive chain
components.
Drive Chain Free Movement
Inspection
Warning
Before starting work, make sure the
motorcycle is stabilised and
adequately supported.
This will help prevent injury to the
operator or damage to the motorcycle.
1
1. Maximum movement position
To inspect the drive chain free
movement:
• Place the motorcycle on a level
surface and hold it in an upright
position with no weight on it.
• Rotate the rear wheel by pushing
the motorcycle to find the position
where the chain is tightest, and
measure the vertical movement of
the chain midway between the
sprockets.
• The vertical movement of the drive
chain must be in the range of 28 -
38 mm.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
