Triumph Daytona Moto2 765 2020 User Manual

Maintenance
115
• Fill the reservoir to the MAX level
line using new DOT 4 brake fluid
from a sealed container.
• Fit the diaphragm seal into the cap
and make sure that the holes for
the fixings in the cap and the
diaphragm seal are correctly
aligned.
ckks
1
2
3
3
1. Reservoir cap
2. Diaphragm seal
3. Fixing holes
• Install the fixings into the cap and
diaphragm seal assembly.
• Hold the assembly together and
position the cap, diaphragm seal and
fixings onto the reservoir.
ckkr
1
2
1. Reservoir cap, diaphragm seal and fixing
assembly
2. Reservoir
Warning
If the master cylinder reservoir cap
screws are over tightened this can
result in a brake fluid leak.
A dangerous riding condition leading
to loss of motorcycle control and an
accident could result if this warning is
ignored.
1
1. Reservoir cap retaining screws
• Tighten the fixings to 0.7 Nm.
Rear Brake Fluid Level Inspection
and Adjustment
Warning
If there has been an appreciable drop
in the level of the fluid in either fluid
reservoir, consult your authorised
Triumph dealer for advice before
riding.
Riding with depleted brake fluid levels,
or with a brake fluid leak is dangerous
and will cause reduced brake
performance potentially leading to loss
of motorcycle control and an accident.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
