Triumph Daytona Moto2 765 2020 User Manual

General Information
64
An adhesive label will be fitted to the
wheel rim to indicate the position of the
tyre pressure sensor, which is near the
valve.
Tyre Pressure Warning Light
(TPMS) (if fitted)
Warning
Stop the motorcycle if the tyre
pressure warning light illuminates.
Do not ride the motorcycle until the
tyres have been checked and the tyre
pressures are at their recommended
pressure when cold.
The tyre pressure warning
light works in conjunction with the Tyre
Pressure Monitoring System (TPMS) (if
fitted).
The warning light will only illuminate
when the front or rear tyre pressure is
below the recommended pressure. It will
not illuminate if the tyre is over inflated.
When the warning light is illuminated,
the TPMS symbol indicating which is the
deflated tyre and its pressure will
automatically be shown in the display
area.
o7:29
12.5
1
9999 02:25
8
6
4
2
0
14
25.2
F
E
TRIP
mi mp/hHH:MM
PM
C
mph
8
6
4
2
0
14
RPM
x1000
10
5
12
36
PSI
F R
18
PSI
3
1
2 4 5
1. Mode button
2. Joystick control
3. TPMS symbol
4. Front tyre indicator
5. Rear tyre indicator
The tyre pressure at which the warning
light illuminates is temperature
compensated to 20°C but the numeric
pressure display associated with it is
not, see page 124. Even if the numeric
display seems at or close to the
standard tyre pressure when the
warning light is on, a low tyre pressure
is indicated and a puncture is the most
likely cause.
Tyre Pressure Sensor Serial Number
The serial number for the tyre pressure
sensor is printed on a label attached to
the sensor. This number may be
required by your authorised Triumph
dealer for service or diagnostics.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
