Triumph Daytona Moto2 765 2020 User Manual

General Information
40
Home button (right
hand switch
housing).
m
Mode button (left
hand switch
housing).
Joystick left/right
or up/down.
Joystick Centre
(press).
Selection arrow
(right shown).
Information Tray -
left/right scroll
using the joystick.
Information Tray -
up/down scroll
using the joystick.
Option available
within the
Information Tray -
scroll using the
joystick up/down.
Short press (press
and release) using
the joystick centre.
Long press (press
and hold) using the
joystick centre.
Reset current
feature, (only
available with
joystick long
press).
Themes and Styles
To select a theme or style, see page53.
Styles can also be selected through the
Style Options tray, see page48.
Theme 1, Style 1 is used for visual
recognition throughout this handbook.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
