Triumph Daytona Moto2 765 2020 User Manual

Maintenance
123
Bank Angle Indicators
Warning
Always replace the bank angle
indicators before they are worn to
their maximum limit.
Use of a motorcycle with bank angle
indicators worn beyond the maximum
limit will allow the motorcycle to be
banked to an unsafe angle.
Banking to an unsafe angle may cause
instability, loss of motorcycle control
and an accident.
Bank angle indicators are located on the
rider's footrests.
2
1
1. Bank angle indicator
2. Wear limit measurement
Regularly inspect the bank angle
indicators on the rider's footrests for
wear. The bank angle indicators are
worn out when 5 mm of the bank
indicator remains.
Tyres
This model is fitted with tubeless tyres,
valves and wheel rims. Use only tyres
marked ‘TUBELESS’ and tubeless valves
on rims marked ‘SUITABLE FOR
TUBELESS TYRES’.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
