Triumph Daytona Moto2 765 2020 User Manual

General Information
66
Sensor Batteries
When the battery voltage in a pressure
sensor is low, a message will be shown
in the instrument display and the TPMS
symbol or message will indicate which
wheel sensor has the low battery
voltage. If the batteries are completely
flat, only dashes will be shown in the
instrument display, the red TPMS
warning light will be on and the TPMS
symbol will flash continuously. Contact
your authorised Triumph dealer to have
the sensor replaced and the new serial
number recorded in the spaces provided
on page64.
With the ignition switch turned to the
ON position, if the TPMS symbol flashes
continuously or the TPMS warning light
remains on there is a fault with the
TPMS system. Contact your authorised
Triumph dealer to have the fault
rectified.
Seats
Seat Care
Caution
To prevent damage to the seat or seat
cover, care must be taken not to drop
the seat. Do not lean the seat against
the motorcycle or any surface which
may damage the seat or seat cover.
Instead, place the seat, with the seat
cover facing upwards, on a clean, flat
surface which is covered with a soft
cloth.
Do not place any item on the seat
which may cause damage or staining
to the seat cover.
See page 146 for seat cleaning
information.

Triumph Daytona Moto2 765 2020 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	765 cc
Compression Ratio	12.9:1
Max Torque	80 Nm @ 9, 750 rpm
Transmission	6-speed
Frame	Aluminium beam twin spar
Dry Weight	165 kg
Seat Height	825 mm
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Max Power	130 PS / 128 bhp (95.6 kW) @ 12, 250 rpm
Front Suspension	Öhlins NIX30 upside down forks, adjustable compression and rebound damping, and preload adjustment
Rear Suspension	Öhlins TTX36 twin tube monoshock, adjustable preload, rebound and compression damping
Rear Brakes	Single 220mm disc, Brembo single piston caliper
Bore x Stroke	78.0mm x 53.4mm
