Triumph Speed Triple R Handbook

105
Maintenance and Adjustment
Speed Triple R
1. Compression damping adjuster
The compression damping adjuster is
accessible from the left hand side of the
motorcycle. It is coloured gold and is situated
close to the rear suspension reservoir.
To adjust the rebound damping setting,
rotate the adjuster clockwise to increase
rebound damping and anti-clockwise to
decrease. Always count the number of clicks
anti-clockwise from the fully clockwise
position noting that the first stop (click
position) is counted as zero.
Note:
• The motorcycle is delivered from
the factory with the rebound
adjuster set at 17 clicks from the
fully clockwise position.
All Models
1
chcx_1
Warning
The rear suspension unit spring pre-load is
not rider adjustable. Any attempt to adjust
the spring pre-load could result in a
dangerous riding condition leading to loss
of control and an accident.

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
