Triumph Speed Triple R Handbook

Specifications
129
Ignition
Ignition System . . . . . . . . . . . . . . . . . . . . . . . . Digital Inductive
Electronic Rev Limiter (r/min) . . . . . . . . . . . . . 9,500 (r/min)
Spark Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . NGK CR8EK
Spark Plug Gap. . . . . . . . . . . . . . . . . . . . . . . . Gap 0.7 mm
Gap Tolerance . . . . . . . . . . . . . . . . . . . . . . . . . +0.05/-0.1 mm
Transmission
Transmission Type . . . . . . . . . . . . . . . . . . . . . . 6 Speed, Constant Mesh
Clutch Type . . . . . . . . . . . . . . . . . . . . . . . . . . . Wet, Multi-Plate
Final Drive Chain. . . . . . . . . . . . . . . . . . . . . . . RK X-Ring
Primary Drive Ratio . . . . . . . . . . . . . . . . . . . . . 1.75:1 (60/105)
Gear Ratios:
Final Drive Ratio . . . . . . . . . . . . . . . . . . . . . . . 2.333:1 (18/43)
1st . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.733:1 (15/41)
2nd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.947:1 (19/37)
3rd . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.545:1 (22/34)
4th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.292:1 (24/31)
5th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.154:1 (26/30)
6th . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.074:1 (27/29)

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
