Triumph Speed Triple R Handbook

12
Parts Identification
PARTS IDENTIFICATION
1. Headlight
2. Radiator/Coolant pressure cap
3. Fuel filler cap
4. Fuel tank
5. Coolant expansion tank
6. Seat lock
7. S il en ce r
8. Rear light
9. Front brake disc
10.Front brake caliper
11. F r o n t i n d i c a t o r
12.Oil cooler
13 . S i d e s t a n d
14.Gear change pedal
15 . D r i v e c h a i n
chcw_2
2 3 4
6
7 8
11
12 13 14 159 10
1
5

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
