Triumph Speed Triple R Handbook

21
General Information
Speedometer and Odometer
The digital speedometer indicates the road
speed of the motorcycle. The read-out
displays the motorcycle road speed in
increments of one kilometre (or mile) per
hour.
The electronic odometer and two trip meters
are in the display screen. For details of the
operation of the odometer and trip meters,
please refer to the following pages.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). At the
end of the tachometer range there is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Trip Computer
1. Display screen
2. Button A
To access the trip computer information press
and release button 'A' until the desired
display is visible. The display will scroll
through in the following order:
• Trip Meter 1;
• Trip Meter 2;
•Lap Timer;
• Tyre Pressure Monitoring system -
if fitted;
•Set up.
Note:
• The lap timer (lap) will only be
displayed if it is turned on in set up
(see page 30).
• The tyre pressure monitoring
system (TPMS) is an accessory
which must be fitted by your
authorised Triumph dealer. The
TPMS display will then be
activated by your authorised
Triumph dealer.
Caution
Never allow engine rpm to enter the
'red zone' as severe engine damage may
result.
2
cfio_12
1

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
