Triumph Speed Triple R Handbook

14
Parts Identification
Parts Identification (continued)
1. C l u t c h l e v e r
2. Passing button
3. Headlight dip switch
4. Speedometer
5. Trip computer display
6. Tachometer
7. Warning lights
8. Front brake fluid reservoir
9. Engine stop switch
10.Front brake lever
11. H o r n b u t t o n
12.Direction indicator switch
13.Ignition switch
14.Immobiliser
15.Starter button
cgfs
432 5 6 7 8 9 10
13 1511 12
1
14

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
