Triumph Speed Triple R Handbook

25
General Information
To access the units display, with the
motorcycle stationary and in neutral turn the
ignition to the ON position.
Press and release button 'A' until set up is
visible in the display screen then press
button 'B'.
Press and release button 'A' until UnitS is
visible then press button 'B'.
1. Display screen
2. Button A
3. Button B
Press and release button 'A' until the desired
display is visible. The display will scroll
through in the following order:
• mpg - Imperial gallons;
• mpg US - US gallons;
• L/100 km - Metric;
•km/L - Metric.
Models without TPMS: Press button 'B'
and do not touch buttons 'A' or 'B' again until
UnitS is visible in the display screen. When
UnitS is visible in the display screen, press
and release button 'A' until r
Eturn is visible
then press button 'B'. Trip 1 will be visible in
the display screen.
Models with TPMS: Press button 'B' and do
not touch buttons 'A' or 'B' again until PSI or
bAr is displayed. Press and release button 'A'
until the desired tyre pressure units are
visible. Press button 'B' and wait until UnitS is
displayed, then press button ’A’ and when
rEturn is displayed press button B. Trip 1 will
be visible in the display screen.
2
3
cfir_12
1

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
