Triumph Speed Triple R Handbook

50
General Information
Tie-Down Hooks
Located on the underside of the seat are the
tie-down hooks.
The tie-down hooks are designed to help
secure a load up to 3.5 kg (7.5 lb) to the seat
using a rope.
To access and use the tie-down hooks,
remove the seat (see page 49).
Release the hooks from the inner clip and
pivot them around and securely fit them into
the outer clips.
Refit the seat as described on page 49.
1. Tie-down hooks
2. Inner clips
3. Outer clips
cgfq
2
3
1
1
Warning
If the seat is used to carry small objects,
they must not exceed 3.5 kg (7.5 lb) in
weight, must not impair control of the
motorcycle, must be securely attached and
must not extend beyond the rear or sides
of the motorcycle.
Carriage of objects in excess of 3.5 kg
(7.5 lb) in weight, that are insecure, impair
control or extend beyond the rear or sides
of the motorcycle may lead to loss of
motorcycle control and an accident.
Even if small objects are correctly loaded
onto the rear seat, the maximum speed of
the motorcycle must be reduced to
80 mph (130 km/h).

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
