Triumph Speed Triple R Handbook

53
General Information
Brake Pads: There should be more than
1.0 mm of friction material remaining on the
front brake pads and more than 1.5 mm for
the rear (see page 93).
Brake Fluid Levels: No brake fluid leakage.
Brake fluid levels must be between the MAX
and MIN marks on both reservoirs (see
page 94).
Front Forks: Smooth action. No leaks from
fork seals (see page 98).
Throttle: Throttle grip free play 2 - 3 mm at
all steering angles. Ensure that the throttle
grip returns to the idle position without
sticking (see page 85).
Clutch: Smooth operation and correct cable
free play (see page 88) at all steering angles.
Coolant: No coolant leakage. Check the
coolant level in the expansion tank (when the
engine is cold) (see page 81 ).
Electrical Equipment: All lights and horn
function correctly (see page 40).
Engine Stop: Stop switch turns the engine
off (see page 56).
Stand: Returns to the fully up position by
spring tension. Return springs not weak or
damaged (see page 48).

Triumph Speed Triple R Specifications

General

Engine Capacity	1050 cc
Transmission	6-speed
Seat Height	825 mm
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, 12-valve, inline 3-cylinder
Power	148 hp (110 kW) @ 10, 500 rpm
Torque	117 Nm at 7, 150 rpm
Front Suspension	Öhlins 43mm NIX30 upside down forks with adjustable preload, rebound and compression damping
Rear Suspension	Öhlins TTX36 monoshock, fully adjustable
Front Brakes	Twin 320mm floating discs, Brembo 4-piston radial calipers
Fuel Tank Capacity	15.5 litres
