Maintenance
117
Note:
• Numbers shown in the diagram
correspond to the fuse numbers in
the table.
Position Circuit Protected Rating
(Amps)
1 Dip and high headlight
beams
15
2 Ignition switch, starter
circuit
10
3 Auxiliary lights 10
4 Engine management
system
15
5 Accessory socket 5
6 Cooling fan 10
7 ABS 25
8 Instruments and alarm 15
9 USB port socket 5
Headlights
Warning
Adjust road speed to suit the visibility
and weather conditions in which the
motorcycle is being operated.
Make sure that the beam is adjusted
to illuminate the road surface
sufficiently far ahead without blinding
oncoming traffic. An incorrectly
adjusted headlight may impair visibility
causing an accident.
Warning
Never attempt to adjust a headlamp
beam when the motorcycle is in
motion.
Any attempt to adjust a headlamp
beam when the motorcycle is in motion
may result in loss of control and an
accident.
Caution
Do not cover the headlight or lens with
any item likely to obstruct air flow to,
or prevent heat escaping from, the
headlight lens.
