Triumph T120 - Coolant Level Inspection

Maintenance
84
Warning
Continued
Coolant that contains anti-freeze and
corrosion inhibitors contains toxic
chemicals that are harmful to the
human body. Never swallow antifreeze
or any of the motorcycle coolant.
Note:
• HD4X Hybrid OAT coolant, as
supplied by Triumph, is premixed
and does not need to be diluted
prior to filling or topping off the
cooling system.
Coolant Level Inspection
Note:
• The coolant level should be checked
when the engine is cold (at room or
ambient temperature).
Street Twin and Bonneville T120
citr
1
2
1. Expansion tank cap
2. MAX and MIN marks
Position the motorcycle on level ground
and in an upright position. The
expansion tank can be viewed from the
left hand side of the motorcycle,
towards the rear of the engine.
Check the coolant level in the expansion
tank. The coolant level must be between
the MAX and MIN marks. If the coolant
is below the minimum level, the coolant
level must be adjusted.
Thruxton and Thruxton R
2
1
1. Expansion tank cap
2. MAX and MIN marks
Position the motorcycle on level ground
and in an upright position. The
expansion tank can be viewed from the
right hand side of the motorcycle,
towards the rear of the engine.
Check the coolant level in the expansion
tank. The coolant level must be between
the maximum (top) and minimum
(bottom) marks. If the coolant is below
the minimum level, the coolant level
must be adjusted.
