Parts Identification
PARTS IDENTIFICATION
Tiger 800 (continued)
15 . R e a r l i g h t
16. Rear brake fluid reservoir
17. Oil filler cap
18. Mirror
19. Headlight adjuster
20. Screen
21. Coolant expansion tank
22. Front fork
23. Clutch cable
24. Engine oil level sight glass
25. Rear brake pedal
26. Rear suspension spring pre-load
adjuster
27. Rear brake caliper
28. Rear brake disc
16 17 18 19 20 21
26
25 24 23 2228 27
