Parts Identification
Tiger 800XC
1. Headlight
2. Front indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. S e a t l o c k
8. Rear wheel adjuster
9. Drive chain
10 . S i d e s t a n d
11. Gear-change pedal
12. Radiator/Coolant pressure cap
13. Front brake caliper
14. Front brake disc
2 3 4 5 6 7
12 11 10 9 814 13
