Triumph Tiger 800 - Tiger 800 XC (continued)

17
Parts Identification
Tiger 800XC (continued)
15 . R e a r l i g h t
16. Rear brake fluid reservoir
17. Oil filler cap
18. Handguards
19. Mirror
20. Headlight adjuster
21. Screen
22. Coolant expansion tank
23. Front fork
24. Clutch cable
25. Engine oil level sight glass
26. Rear brake pedal
27. Rear suspension pre-load adjuster
28. Rear suspension rebound damping
adjuster
29. Rear brake caliper
30. Rear brake disc
