Trojan Glide Cycle 500 User Manual

8
TG500
No. Description
57 Bolt M10 × 18 2
58 Bearing 2
59 Nut M6 2
60 Open-End Wrench 1
61 Bolt M10 × L55 × L25 2
62 Pedal Hinge Bolt Φ15.6 × 88.8 × 1/2” × 24.5 1
63 Pedal Hinge Bolt Φ15.6 × 88.8 × 1/2” × 24.5 1
64 Seat 1
65 Washer D8 3
66 Nylon Nut M8 3
67 Saddle Tube 1
68 Seat Post 1
69 Square Bushing 1
70 Handlebar Line 2
71 Solid Wrench S13 - 17 - 19 1
72 Socket Head Wrench S6 2
73 Socket Head Wrench S8 1
74 Spile 2
75 Middle Line 1
76 Tube Plug 4
77 Washer D8 3
78 Hexagon Bolt M8 2
No. Description
79 Handlebar Post 1
80 Nut M6 2
81 Plastic Roller 2
82 Bolt M6 X 48 2
83 Bolt M5 4
84 Handlebar Grip 2
85 Washer D8 1
86 Bolt St4.2 X 16 1
87 End Cap 2
88 Washer Φ16 × 1 × 1 × Φ28 2
89 Square Bushing 1
90 End Cap 1
91 Nut M6 1
92 Skate Brake 1
93 Nut M5 5
94 Bolt M5 X 30 2
95 Washer 1
96 Nut M5 X 16 1
97 Water Bottle 1
98 Bottle Holder 1
99 Bolt M5 X 16 2
100 Middle Handlebar 1
PARTS LIST
