7
TG500
PARTS LIST
No. Description
1 Main Frame 1
2 Front Bottom Tube 1
3 Back Bottom Tube 1
4 Right Coupler Bar 1
5 Left Coupler Bar 1
6 R Right Pedal Tube 1
6 L Left Pedal Tube 1
7 R Right Handle Bar 1
7 L Left Handle Bar 1
8 R Right Chain Cover 1
8 L Left Chain Cover 1
9 End Cap S16 4
10 Bolt M8 X 35 2
11 Pedal 2
12 Handle Bar Shaft 1
13 End Caps (Φ2") 2
14 Foam Grips 2
15 End Caps (Φ1") 8
16 Plastic Bushing (Φ1-1/4") 4
17 Knob Bolt 5
18 End Caps (Φ2") 2
19 Steel Bushing Φ24 × 20 × Φ16.1 10
20 Steel Bushing Φ14 × 12.5 × Φ10.1 4
21 Washer D8 X Φ16 X 1.5 X R15 2
22 Fan Wheel Axle 1
23 Nut M10×1×B5 4
24 Nut M10 2
25 Nut M10×1×B10×Φ20 2
26 Plastic Insert 1
No. Description
27 Crankshaft 1
28 Plastic Cap 2
29 Washer 1
30 R Collar Housing R 1
30 L Collar Housing L 1
31 Collar Ball 2
32 Collar Housing 2
33 Nut 1
34 Chain 80Z 1
35 End Cap 2
36 Flywheel 1
37 Computer Line I 1
38 Chain Cover Screw St4.8 × 20 6
39 Chain Cover Screw St4.8 × 48 6
40 Nut M8 2
41 End Cap 1
42 Bolt M6 × 36 2
43 End Cap S19 2
44 Bolt M10 × 45 4
45 Nylon Nut M10 6
48 L/R Nylon Nut 1/2"× B8 2
49 Arc Washer Φ10 ×1.5 × Φ25 × R25.5 4
50 Computer 1
51 Spring Washer Φ10.5 × 3 × Φ18 2
52 Washer Φ16 × 1 × 2.5 × Φ28 1
53 Square End Cap 2
54 End Cap S14 4
55 Washer 1
56 D Shape Washer Φ28 × Φ16.2 × 14 × B5" 2
