PARTS LIST
No. Description Qty
1 Main Frame 1
2 Base Frame 1
3 Left Upright Tube 1
4 Right Upright Tube 1
5 Console Bracket 1
6 Screw (ST4.2 X 25) 4
7 Rubber Pad 4
8 Lock Washer (Ø10) 8
9 Front Roller 1
10 Rear Roller 1
11 Cylinder 1
12 Allen Wrench (5 mm) 1
13 DC Motor 1
14 Running Board 1
15 Bolt (M5 X37) 4
16 Spring 2
17 Inclined Tube Plug 2
18 Motor Cover 1
19 Screw (ST4.2 X 19) 2
20 Side Rail 2
21 Right Back End Cap 1
22 Left Back End Cap 1
23 Rubber Pad 2
24 Motor Belt 1
25 Power Wire Buckle 1
26 Running Belt 1
27 Foot Pad 4
28 Ring Wire Protector Plug B 2
29 Moving Wheel 2
No. Description Qty
30 Bolt (M6 X 37) 2
31 Standard Power Wire 1
32 Switch 1
33 Foam 2
34 Screw (ST4.2 X 13) 11
35 Console Panel 1
36 Console Bottom Cover 1
37 Tablet Rack 3
38 Hand Pulse With Speed 10
39 Hand Pulse With Incline 4
40 Control Board 1
41 Console Bottom Wire 2
42 Console Top Wire 4
43 Barb Cushion 2
44 Magnetic Ring 3
45 Brown Single Wire 2
46 Bolt (M8 X 25) 2
47 Lock Nut (M6) 1
48 Screw (ST4.2 X 30) 5
49 Motor Bottom Cover 6
50 Barb Cushion 12
51 Bolt (M8 X 16) 12
52 Bolt (M8 X 40) 3
53 Bolt (M8 X 42) 1
54 Bolt (M10 X 55) 2
55 Lock Washer C Level 4
56 Bolt (M6 X 55) 2
57 Bolt (M5 X 8) 2
58 Lock Nut (M8) 1
