Chapter 6: Plumbing 2503 Center Console • Owner’s Manual Supplement
Drain Systems
Deck & Fish Well Drains
• Water on the deck and in the fish
wells drains overboard.
• Keep the drains free of debris.
FISH WELL
DRAIN
NOTE: VIEW IS UNDERSIDE OF DECK
DECK
DRAINS
DECK
DRAINS
SINK
DRAIN
FISH WELL
DRAIN
