Chapter 9: Electrical System 2503 Center Console • Owner’s Manual Supplement
Console 12-Volt Wire Harness Routing
Hardtop 12-Volt Wire Harness Routing (If Equipped)
HORN
COMPASS
SWITCH PANEL
THROTTLE/SHIFTER
GAUGE PANEL
DASH LIGHT
TRIM TABS
HEAD LIGHT
FUSE BLOCK
GROUND BUSS
MAIN POWER STUD
HEAD LIGHT
NOTE: VIEW IS UNDERSIDE OF HARDTOP
ALL AROUND
LIGHT
OVERHEAD
LIGHT
FUSE
BLOCK
SPOTLIGHT
OVERHEAD
LIGHT
HARNESS
PLUG
