2503 Center Console • Owner’s Manual Supplement Chapter 9: Electrical System
Hull 12-Volt Wire Harness Routing
FORWARD
BILGE PUMP
AFT
BILGE PUMP
WATER PUMP
(IF EQUIPPED)
MACERATOR
(IF EQUIPPED)
MACERATOR SWITCH
(IF EQUIPPED)
