Press the 〈ALPHA LOCK〉 key to enable the alphabetic keys on
the gauge. When the alphabetic keys are enabled, the symbol
A appears in the upper right of the display, as shown above.
Enter a unique mix calibration ID and press 〈ENTER/START〉.
The gauge displays:
The gauge can store the mix calibration in one of four
memory cells. Use the numeric keys to store the mix
calibration. Note that this will replace any mix calibration that
was previously stored in that cell.
The gauge enables the mix calibration, displays a brief
confirmation message, and returns to the Setup menu.
Slope/Intercept
The Slope/Intercept function is used to manually enter the
slope and/or intercept for a particular material. These values
can be determined using the Data Pairs function described on
page 3–7, or can be calculated manually.
To access the Slope/Intercept function, press 〈2〉 on the Entry
Method menu shown on page 3–7. The gauge prompts for
the slope and intercept values. Press
〈ENTER/START〉 after
each value is entered. After both values have been entered,
the gauge displays:
1. Empt y 2. Empt y
3. Empt y 4. Empt y
Pr ess # To Sel ect
I nt er cept = ###. #
Do you want t o
accept t hi s mi x?
