Installation
Truma iNet X Panel / Truma iNet X Pro Panel
EN

Push the right and left sliding latches (Fig� 5-1) on
the control panel against the springs (Fig� 5-2) until
they click into place on the housing (Fig� 5-3)�
1
2
1
3
Fig� 5

Insert the control panel into the installation opening
from below (Fig� 6-1)�

Gently press the housing against the installation wall
(Fig� 6-2) until you hear the sliding latches click into
the top edge of the installation opening�
1
2
Fig� 6

Truma iNet X Panel Specifications

General

Display Type	TFT
Screen Size	4.3 inches
Power Supply	12 V DC
Weight	150 g
Connectivity	Bluetooth
Current Consumption at 12 V	200 mA
Interfaces	USB
