Trust Automation, Inc. TA333 High Power Linear Servo Amplifier
10-Apr-09 Page 20 of 38
Current vs. Time
5
7
9
11
13
15
17
19
21
23
25
500 1500 2500 3500 4500 5500 6500
Time (ms)
Current
Figure 9 – Output Current vs. Time Graph for Time to Fault @ ~30°C
Wattage vs. Time
600
700
800
900
1000
1100
1200
1300
1400
15 25 35 45 55 65 75 85
Time (ms)
Wattage
Figure 10 – Dissipation Wattage vs. Time for Time to Fault @ ~30°C
