TSC Alpha-30L User Manual

25
3.8 Connecting to the Printer
The printer must establish communication with a host terminal which sends the data to be printed.
There are 3 ways to connect for Alpha-30L series:Cable, Bluetooth, and Wireless LAN.
3.8.1 Cable Communication
1. Open the interface cover
2. Connect the printer to the computer/smart phone (host terminal)
with Type C cable. (Type C to USB)
3.8.2 Wireless Communication with Bluetooth
1. Turn on the printer.
2. Enable the Bluetooth for mobile device to search (local name) and to connect the printer's Bluetooth module.
Note:Use the menu (or self-test printout) to check the Bluetooth local name.
(Menu  Interface  Bluetooth  Local Name)
3. Once the Bluetooth module is connected with the mobile device, the Bluetooth logo will be displayed on the LCD control panel.
3.8.3 Wireless Communication with Wi-Fi
 Please refer to chapter 5.2 for the detailed setting.
Type C

TSC Alpha-30L Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Printable dot numbers	8 dot
Maximum printing width	72 mm
Core diameter	12.7 mm
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	67 mm
Supported paper width	80 mm
Ethernet LAN	No
Optional connectivity	Bluetooth, USB 2.0
Connectivity technology	Wired & Wireless
Internal memory	128 MB
Built-in barcodes	1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languages	ESC/POS, TSPL-EZ
Display	LCD
Control type	Buttons
Product color	Black, Grey
Display diagonal	2.3 \
Display resolution	320 x 240 pixels
Battery capacity	3030 mAh
Warranty period	2 year(s)
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	117 mm
Height	173 mm
