TSC Alpha-30L User Manual

46
5.5 Printer Function
Printer Function could be found in Printer Configuration. “Printer Function” will be shown on the left side of the window.
Functions
Description
Calibrate Sensor
Detect media types and the size of the label
RTC Setup
Synchronize printer with Real Time Clock on PC
Factory Default
Initialize the printer to default settings
Reset Printer
Reboot printer
Print Test Page
Print test page according to the specified label size and sensor type.
Configuration Page
Print printer configurations
Dump Text
Activate the printer to dump mode
Ignore AUTO.BAS
Ignore AUTO.BAS file when printer boot up.
Exit Line Mode
Exit the line mode to page mode
Enter Line Mode
Leave page mode and enter line mode
Reset WiFi
Restore the WiFi settings to defaults.

TSC Alpha-30L Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Printable dot numbers	8 dot
Maximum printing width	72 mm
Core diameter	12.7 mm
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	67 mm
Supported paper width	80 mm
Ethernet LAN	No
Optional connectivity	Bluetooth, USB 2.0
Connectivity technology	Wired & Wireless
Internal memory	128 MB
Built-in barcodes	1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languages	ESC/POS, TSPL-EZ
Display	LCD
Control type	Buttons
Product color	Black, Grey
Display diagonal	2.3 \
Display resolution	320 x 240 pixels
Battery capacity	3030 mAh
Warranty period	2 year(s)
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	117 mm
Height	173 mm
