TSC Alpha-30L User Manual

35
4.7 File Manager
File Manager is used to check the printer available memory, show the files list, delete the files or run the files that saved in the
printer DRAM/Flash/Card memory.
Item
Description
DRAM
Use this menu to show, delete and run (.BAS) the files saved in the printer DRAM memory.
FLASH
Use this menu to show, delete and run (.BAS) the files saved in the printer Flash memory.
CARD
Use this menu to show, delete and run (.BAS) the files saved in the SD card on printer.
Note:This subsection will only be visible when the SD card installed.
Menu File Manager
DRAM
FLASH
CARD

TSC Alpha-30L Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Printable dot numbers	8 dot
Maximum printing width	72 mm
Core diameter	12.7 mm
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	67 mm
Supported paper width	80 mm
Ethernet LAN	No
Optional connectivity	Bluetooth, USB 2.0
Connectivity technology	Wired & Wireless
Internal memory	128 MB
Built-in barcodes	1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languages	ESC/POS, TSPL-EZ
Display	LCD
Control type	Buttons
Product color	Black, Grey
Display diagonal	2.3 \
Display resolution	320 x 240 pixels
Battery capacity	3030 mAh
Warranty period	2 year(s)
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	117 mm
Height	173 mm
