27
4.2 Main Menu Overview
There are 6 categories on the menu. Users can easily set the settings of the printer without connecting the computer. Please refer
to following sections for more details.
Setting : To set up the printer settings for TSPL &
ZPL2.
File Manager : To check and manage printer’s
memory storage.
Advanced : To set LCD, initialization, cutter
type,…etc.
Sensor : To calibrate the selected media sensor.
Interface : To set the printer interface settings.
Diagnostic : To check printer and help users to
troubleshoot the problems.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TSC Alpha-30L and is the answer not in the manual?

TSC Alpha-30L Specifications

General IconGeneral
ColorYes
Print technologyDirect thermal
Maximum resolution203 x 203 DPI
Printable dot numbers8 dot
Maximum printing width72 mm
Core diameter12.7 mm
Media thickness0.06 - 0.16 mm
Maximum roll diameter67 mm
Supported paper width80 mm
Ethernet LANNo
Optional connectivityBluetooth, USB 2.0
Connectivity technologyWired & Wireless
Internal memory128 MB
Built-in barcodes1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languagesESC/POS, TSPL-EZ
DisplayLCD
Control typeButtons
Product colorBlack, Grey
Display diagonal2.3 \
Display resolution320 x 240 pixels
Battery capacity3030 mAh
Warranty period2 year(s)
Storage temperature (T-T)-30 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth79 mm
Width117 mm
Height173 mm
