TSC Alpha-30L User Manual

43
5. After clicking Set button, it'll pop-up the window tip
as below shown.
6. IP address will be shown in the “IP address” field
and the Wi-Fi logo and IP address will be displayed
on the LCD control panel as shown below. The Wi-
Fi module has been connected.
Note:
IP address should be shown within about 5~15
seconds after printer turn on. If not, please refer to
steps below to initialize the printer Wi-Fi module
settings then to setup it again.
7. Remove the Type C cable between the computer
and the printer.
8. Go to main page, click Add Printer to add the
printer via Network.
9. Select the printer and enter the setting page by
double clicking the printer.
10. Click the Print Test Page button to print the test
page via Wi-Fi interface.

TSC Alpha-30L Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Printable dot numbers	8 dot
Maximum printing width	72 mm
Core diameter	12.7 mm
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	67 mm
Supported paper width	80 mm
Ethernet LAN	No
Optional connectivity	Bluetooth, USB 2.0
Connectivity technology	Wired & Wireless
Internal memory	128 MB
Built-in barcodes	1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languages	ESC/POS, TSPL-EZ
Display	LCD
Control type	Buttons
Product color	Black, Grey
Display diagonal	2.3 \
Display resolution	320 x 240 pixels
Battery capacity	3030 mAh
Warranty period	2 year(s)
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	117 mm
Height	173 mm
